What Is the Surface Overflow Rate Formula?
The surface overflow rate formula is SOR = Flow (gpd) ÷ Surface Area (ft²). It calculates how fast water rises through a clarifier - and whether solids have enough time to settle out before they escape over the weirs.
SOR (gpd/ft²) = Flow (gpd) / Surface Area (ft²)
That's it. One division problem. But the exam will test whether you can get your units lined up before you divide, and that's where most operators lose points.
Why Does Surface Overflow Rate Matter in Clarifier Operation?
Think of SOR as a speed limit for your clarifier. If water's rising too fast, solids don't have time to settle. They ride the upflow right over the weirs and blow your effluent TSS. Too slow, and you might be wasting tank capacity or dealing with septic conditions from sludge sitting too long.
When you're troubleshooting a clarifier that's losing solids, the clarifier overflow rate is one of the first things to check. Did flow spike from a rain event? Did someone take a clarifier offline for maintenance, forcing all the flow through fewer tanks? Both situations jack up your SOR and can push you past design limits.
Typical rule-of-thumb design SOR values at average daily flow for secondary clarifiers fall in the range of 400 to 800 gpd/ft². Primary clarifiers usually run higher, around 600 to 1,200 gpd/ft². Your plant's design engineer picked a specific value based on expected flows, but the exam cares that you can calculate the actual SOR and know whether it's in a reasonable range.
How Do You Calculate Clarifier Surface Area?
Here's where the exam likes to get tricky. They won't always hand you the surface area on a silver platter. Instead, you'll get a clarifier diameter and need to calculate the area yourself.
Area (ft²) = 0.785 x [Diameter (ft)]²
That 0.785 is just pi divided by 4 (3.14 / 4 = 0.785). It's the shortcut every operator should have memorized. You'll see it on detention time calculations and dozens of other problems involving circular tanks.
Exam Tip
Many certification exams give you diameter and make you calculate area. If you forget 0.785 x D², you're stuck. Burn this one into memory - it shows up on clarifier, digester, and aeration basin problems alike.
Worked Example: Basic SOR Calculation
Worked Example
Given: A circular secondary clarifier has a diameter of 60 ft. The plant flow is 1.5 MGD. What is the surface overflow rate in gpd/ft²?
Step 1: Convert flow from MGD to gpd 1.5 MGD x 1,000,000 = 1,500,000 gpd
Step 2: Calculate the clarifier surface area Area = 0.785 x (60 ft)² Area = 0.785 x 3,600 ft² Area = 2,826 ft²
Step 3: Plug into the SOR formula SOR = 1,500,000 gpd / 2,826 ft²
Step 4: Divide SOR = 530.8 gpd/ft²
Answer: SOR = 531 gpd/ft²
That's a reasonable number for a secondary clarifier. If you got something like 5,000 or 53, you know you messed up a unit conversion somewhere.
Worked Example: Multiple Clarifiers in an SOR Calculation
This is the version that trips people up on the exam. When multiple clarifiers are in service, you divide the flow among them.
Worked Example
Given: A plant has three secondary clarifiers, each 50 ft in diameter. Two are in service and one is offline for maintenance. The plant flow is 2.0 MGD. What is the SOR?
Step 1: Convert flow to gpd 2.0 MGD x 1,000,000 = 2,000,000 gpd
Step 2: Calculate the surface area of ONE clarifier Area = 0.785 x (50 ft)² Area = 0.785 x 2,500 ft² Area = 1,962.5 ft²
Step 3: Calculate TOTAL surface area in service (2 clarifiers) Total Area = 1,962.5 ft² x 2 = 3,925 ft²
Step 4: Calculate SOR SOR = 2,000,000 gpd / 3,925 ft² SOR = 509.6 gpd/ft²
Answer: SOR = 510 gpd/ft²
Exam Tip
Read the problem carefully. If it says "three clarifiers but one is out of service," you only use the area of the two that are running. This is one of the most common traps on clarifier questions. The exam wants to see if you're paying attention or just using all three.
Common Exam Traps and Mistakes
Forgetting to convert MGD to gpd. The SOR formula needs gallons per day, not million gallons per day. If you plug in 1.5 instead of 1,500,000, your answer will be off by a factor of a million. It'll look absurdly small, but under exam pressure, people second-guess themselves and move on.
Using diameter instead of radius (or vice versa). The 0.785 x D² shortcut uses diameter. If you're using the full pi x r² formula, you need to divide the diameter by 2 first to get the radius. Mixing these up gives you an area that's off by a factor of 4.
Using total clarifiers instead of in-service clarifiers. As shown in the second example, many certification exams include this trap. Always count only the units that are actually receiving flow.
Radius vs. diameter given. Some problems give you the radius directly. If the problem says "a clarifier with a 30-ft radius," that's a 60-ft diameter. Read carefully.
Mixing up SOR and weir overflow rate. The surface overflow rate uses the entire surface area of the clarifier. The weir overflow rate uses the length of the weir (usually the circumference). They're different calculations testing different things. SOR checks settling capacity; weir overflow rate checks turbulence at the outlet.
SOR vs. Hydraulic Loading Rate
You'll sometimes see "hydraulic loading rate" used interchangeably with surface overflow rate. For exam purposes, they're the same calculation - flow divided by area. The difference is context. SOR typically refers to clarifiers specifically, while hydraulic loading rate can apply to filters, sand beds, or any treatment unit where flow is distributed over an area. If the exam asks for either one on a clarifier problem, use the same formula.
When Would You Use SOR on the Job?
Beyond exam day, SOR helps you make real operational decisions:
- Rain events: When influent flow doubles during a storm, your SOR doubles too. Knowing the number helps you decide whether to bring a standby clarifier online.
- Clarifier maintenance: Before pulling a clarifier offline, calculate what the SOR will be on the remaining units. If it pushes past your design limits, you might need to schedule the work during low-flow periods.
- Permit compliance: If your effluent TSS is creeping up, a high SOR might be the reason. It gives you data to bring to your supervisor instead of just saying "the clarifier's not working right."
NPDES permits
- issued by your state agency or EPA - set the effluent limits you're trying to meet, and proper clarifier operation is a big part of hitting those numbers consistently.
Key Takeaway
The surface overflow rate formula is SOR = Flow (gpd) ÷ Surface Area (ft²). It measures how fast water rises through a clarifier. Typical secondary clarifier SOR ranges from 400 to 800 gpd/ft²; primary clarifiers range from 600 to 1,200 gpd/ft². For the exam, always convert MGD to gpd first, calculate area using 0.785 x D², and only count the clarifiers that are actually in service.
Quick Reference
| Parameter | Typical Range |
|---|---|
| Primary clarifier SOR | 600 - 1,200 gpd/ft² |
| Secondary clarifier SOR | 400 - 800 gpd/ft² |
| Area formula (circular) | 0.785 x D² |
| MGD to gpd | Multiply by 1,000,000 |
Keep this formula in your back pocket. It's a straightforward calculation once your units are clean, and it's one of those problems you can bank as a sure thing on exam day - as long as you don't rush through the unit conversions.
